| SOC： | Allwinner H727 |
| OS： | Android 14.0 |
| Wi-Fi： | 2.4G+5G+WiFi6+BLE |
| Resolution: | 1920*1080 |
| Brightness: | 500ANSI lumens |
| Technique: | 3.5-inch TFT LCD Display |
| Throw Ratio： | 1.2:1 |
| Focusing: | Automatic focus |
| Projection Size: | 40-140 inch |
1.Ultra-Clear Visual Performance
Native 1920×1080P resolution with 3-piece glass lens, 1000:1 high contrast for clear details. 500 ANSI lumens and 5500–8500K color temperature deliver natural, realistic colors.
2.Long-Lasting Sealed Optical Engine
Fully sealed optical engine prevents dust and reduces wear. LED light source lasts 30,000+ hours for stable brightness. 1.2:1 throw ratio supports 40–140 inch large-screen projection.
3.Smart Correction & Obstacle Avoidance
Auto focus, auto keystone correction, and intelligent obstacle avoidance. Supports ±30° side projection, automatically adjusts for a perfect, clear rectangular image.
4.Powerful System Performance
Powered by Allwinner H727 quad-core chip with Android 14.0 for smooth operation. Multiple RAM and storage options available for different needs.
5.High-Speed Stable Connectivity
Dual-band WiFi 6 (2.4G+5G) + BLE for fast, stable connection. Smooth wireless screen mirroring and streaming without lag.
| Basic Parameters | |
| Model Number： | C35A |
| Processor： | Allwinner H727 |
| DRAM: | 1GB (2GB,4GB Optiona) |
| Flash: | 16GB (32/64GB Optional) |
| Operation System | Android 14.0 |
| WIFI： | WiFi:802.11 a/b/g/n/ac/ax(2.4G+5G+WiFi6+BLE) |
| Optics | |
| Technique： | 3.5-inch TFT LCD Display |
| Resolution： | 1920*1080 |
| Brightness： | 500 ANSI lumens |
| Contrast Ratio： | 1000:1 |
| Optical machine type: | Sealed Optical Engine |
| Lens： | 3 pieces glass lens |
| Throw Ratio： | 1.2:1 |
| Bulb Life： | 30000+ Hrs |
| Lamp Power： | 56~70W |
| Item Size： | 250mm*230mm*230mm |
| Projection Distance： | 1.15-4m |
| Projection Size： | 40~140 inch |
| Keystone Correction： | Automatic keystone correction |
| Focusing： | Automatic focus |
| Other Attributes | |
| Place of Origin： | Guangdong, China |
| Brand Name | IK WORLD |
| Warranty： | 1 years |
Pictures & specifications for reference only. Contact our sales team for details.
Product Details
C35A is a powerful Android 14 projector built around the Allwinner H727 processor, supporting flexible RAM & Flash configuration with optional 2GB/4GB DRAM and 32GB/64GB storage. As a good projector for home and light commercial usage, it ranks among good affordable projectors on the market. Equipped with a sealed optical engine and 3‑piece glass lens, this home cinema projector delivers 500 ANSI lumens brightness, auto focus and automatic keystone correction. Its 1.2:1 throw ratio creates an immersive viewing experience as a portable projector and screen combo for 40‑140‑inch large projection. Featuring WiFi 6 & BLE connection and a long 30000+‑hour light‑source lifespan, this amazon‑ready wholesale LCD projector is ideal for home entertainment and small‑scale commercial scenarios. We support bulk wholesale and customized OEM services for global importers and brand partners. Refer to FAQs below for technical details, sample policy, MOQ and export certifications.
1.C35A uses Allwinner H727 chip and Android 14 OS, can we upgrade RAM and Flash for our project?
Yes, 2GB/4GB DRAM and 32GB/64GB Flash are optional variants. Different memory combinations will affect MOQ and unit price. Please contact our sales to confirm your target configuration.
2.This C35A comes with sealed optical engine and 500 ANSI lumens, how about dust‑proof performance and long‑term picture stability?
The sealed optical engine effectively reduces dust ingress, slowing down yellowing and dust spot issues after long‑time use. It is optimized for home & light commercial usage. For 24‑hours non‑stop heavy commercial operation, please consult our sales for suggestions.
3.C35A supports auto focus & automatic keystone correction, what projection distance range does it work best within?
Optimized performance within 1.15‑4m projection distance for 40‑140‑inch screen. Picture effect may decline if beyond this distance range.
4.With 3‑pieces glass lens and 30000+ hours bulb life, do we need to replace lamp module during normal product lifecycle?
Under regular household usage, lamp replacement is not required. If you run the device at high brightness for very long hours continuously, light attenuation will happen gradually.
5.C35A integrates WiFi6 + BLE, what wireless connection features are available for end‑users?
It supports dual‑band WiFi 2.4G+5G for screen mirroring; BLE enables bluetooth speaker connection and peripheral pairing.
1.What is the MOQ for stock C35A units? If I select upgraded 4GB+64GB configuration, will MOQ change?
MOQ for standard stock version is 100 units. Higher‑spec memory options belong to OEM customized build, which requires higher MOQ. Please get exact quotation from our sales team.
2.Can we customize boot logo and housing silk‑print for C35A under Android14 system? What are the relevant requirements?
Housing silk‑print is available with certain MOQ. Boot‑logo and system modification need higher MOQ. Cost and lead‑time will be assessed according to your customization list.
3.We will import C35A to overseas markets, what certifications can you supply for this projector?
CE & RoHS are provided for standard stock model. For FCC, UKCA and other regional certificates, we can provide supporting documents. If we apply certificates on buyer’s behalf, related fees shall be covered by buyer and production lead‑time will extend.
4.Can I order C35A sample for market validation? Is sample fee refundable for bulk purchase?
Sample order is acceptable. Sample cost and freight shall be borne by buyer. Sample fee can be deducted from future large‑volume C35A orders.
5.What marketing assets can you offer for C35A? And what is the warranty term for bulk orders?
We provide official spec sheets, product renderings and posters. C35A carries 1‑year warranty. For additional custom‑shot marketing materials, please negotiate with our sales for terms.
